03.5850 - SCANGRIP ZONE 2 LED rechargeable headlamp providing up to 200 lumen

RECHARGEABLE HEADLAMP WITH 200 LUMEN
The new ZONE 2 headlamp provides optimum work light illuminating the entire field of view. It is now delivering even more value for money for the professional user.

The light output was increased by 33 % from 150 to 200 lumen,
and with improved battery technology and now three light settings,
including the new »reading mode«, the maximum operating time was
increased to 22 hours.

The design has become more compact, modern and user-friendly,
and the new ZONE 2 also features a battery indicator and upgraded
IP rating to IP54.

The upgraded ZONE 2 comes with 3-step function. The first step is reading mode providing 20 lumen, that is just enough light to read a manual.

Why you should choose ZONE 2?
• Lights up your entire field of view
• New reading mode setting
• 22 hours operating time
• Improved battery technology
• Compact and user-friendly design


Net Weight (kg)
0.08
Length (mm)
0.84
Width (mm)
31.50
Height (mm)
0.37
Gross weight, packaging (kg)
0.14
Length, packaging (mm)
104.00
Width, packaging (mm)
90.00
Height, packaging (mm)
41.00
Sales display included
No
Qty in outer box
24.00


Luminous Flux, Max (Lumen)
200
Luminous Flux, Min (Lumen)
20
Illuminance, Max (Lux@0,5m)
400
Illuminance, Min (Lux@0,5m)
40
LED performance (lm/w)
155
CCT (Kelvin)
6000
CRI
Ra > 80
Adjustable Light Output
3 steps
Beam Angle Main
120°/60°


Power source
Rechargeable Battery
Battery type
Li-Polymer
Battery capacity (mAh)
1200
Battery voltage (V)
3.70
Cable
1m USB charging cable
Charging voltage DC (V)
5.00
Charging current (A)
0.00
Charging input voltage (V)
100-240V AC 50/60Hz
Power Consumption (W)
2.50
Charger included
No



Operating time with max. lumen (hours)
2.00
Charging time (hours)
2.50
Ingress protection
IP54
Impact protection
IK07
Operating temperature (°C)
-10 °C to +40 °C
Impact resistance (meter)
1.00
Operating time with min. lumen (CAS/hours)
22
